| Application Area | Gas ( Dry non-humid gases ) |
| Temperature | -40 … +230 °C |
| Pressure | Max. 40 bar |
| Connection Size | DN25 … DN 600 |
| Connection Range | Threaded Connection |
| Measuring Range | 0…150 m/s |
| Wet Portions | Stainless Steel |
| Connection Portions | Stainless Steel |
| Analog Output Signal | 4…20 mA / 0…10 VDC / 0…5 VDC |
| Communication Protocol | RS485 Modbus, HART , Profibus PA |
| Foundation Fieldbus | |
| Supply Voltage | 24 VDC |
| Protection Class | IP65 / IP67 |
| Approval | Ex d , Ex ia |
| Precision | % 1 Std. ( %0,5 .. %0,2 Opt.) |
| Indicator Options | Compact , Remote |
| Indicator Paremeters | Instant and Total Flow |
| Quality Certifaces | IS09001 / CE |
